Measuring the signal centroid is an essential task in signal processing, as it provides insights into the signal's characteristics and can help in various applications such as image processing, audio analysis, and more. In this article, we will explore how to compute the signal centroid using Python.

What is Signal Centroid?

The centroid of a signal is a measure of the "center of mass" of the signal's amplitude distribution. Mathematically, it can be defined as the weighted average of the time indices of the signal, where the amplitude values act as weights.

How to Calculate Signal Centroid

The signal centroid ( C ) can be calculated using the following formula:

[ C = \frac{\sum (t_i \cdot x_i)}{\sum x_i} ]

Where:

• ( t_i ) is the time index
• ( x_i ) is the amplitude of the signal at time ( t_i )

Step-by-Step Implementation in Python

1. Install Required Libraries: Make sure you have NumPy and Matplotlib installed. You can install them using pip if you haven't done so already.

   pip install numpy matplotlib


2. Import Libraries:

   import numpy as np
   import matplotlib.pyplot as plt


3. Create a Sample Signal:

   # Time array
   t = np.linspace(0, 1, 500)  # 1 second of data at 500 Hz
   # Sample Signal (e.g., a sine wave)
   x = np.sin(2 * np.pi * 5 * t)  # 5 Hz sine wave


4. Calculate Signal Centroid:

   # Compute the centroid
   numerator = np.sum(t * x)  # Weighted sum of time indices
   denominator = np.sum(x)     # Sum of amplitude values
   centroid = numerator / denominator


5. Display the Results:

   print(f"Signal Centroid: {centroid:.4f} seconds")


6. Visualize the Signal and its Centroid:

   plt.figure(figsize=(10, 6))
   plt.plot(t, x, label='Signal')
   plt.axvline(centroid, color='r', linestyle='--', label=f'Centroid at {centroid:.4f} s')
   plt.title('Signal and its Centroid')
   plt.xlabel('Time (seconds)')
   plt.ylabel('Amplitude')
   plt.legend()
   plt.grid()
   plt.show()


Conclusion

Calculating the signal centroid in Python is straightforward with the help of libraries like NumPy for mathematical computations and Matplotlib for visualizations. The centroid provides valuable insights into the signal's properties and can be used as a feature for various applications in signal processing.

By following the steps outlined above, you should be able to compute the signal centroid for any given signal. Whether you are analyzing audio signals, sensor data, or any other form of digital signal, understanding the centroid can enhance your analysis and understanding of the underlying data.
